Ultra-Rugged All-Touch Computer with Zebra 2D scanner (LP-116)

Category:

The Ultimate in Ultra-Rugged Enterprise-Class All Touch Computing Inside the Four Walls and Outdoors

The Ultimate in Technology Advancements
The LP-116 have it all: maximum computing power; rich locationing support; power-saving faster WiFi connections;
superior barcode capture; high-quality voice; 13/20 MP color rear camera for photos and videos; Powerful octa-core porcessor, ARM 4 core Cortex-A73 & 4 core Cortex-A53 adding 2.0GHz, Memory up to 4G+64G

The Ultimate Rugged Design
The LP-116 are designed to withstand years of the toughest conditions.
The device is virtually waterproof, drop-proof, dust-proof and tumble proof, with a 5.5inch Gorilla Glass touch panel and imager window that offer maximum scratch-resistance and shatter proofing.

Extended battery life with Worryfree WIFI
LP-116 adopts 4900mAh/9000mAh(option)Li-ion battery with lasting endurance. Advanced 12nm FinFET battery low power management prolongs the battery life greatly. Get the ultimate in value-add features. Get dependably superior WiFi connections with WorryFree WiFi.

PHYSICAL CHARACTERISTICS
Dimensions 166×79×18±2mm
Weight N.W: 400g
Display 5.5 inch IPS HD,dpi 720*1440
Touchpanel Corning Gorilla Glass 3rd generation
Multi-touch capacitive screen
Expansion Slot 1pcs Sim(MUP-C785)、1pcs TF
1pcs PSAM(MUP-C785)
Communication 1pcs Type-c
Backlight LED backlight
Keypad Scan key, Number key
GPS GPS and Beidou navagtion option
Error range±5m
Camera Front: 5MP fixed focus
Rear: 13 MP& 20 MP option
Autofocus; flash LED generates balanced
PERFORMANCE CHARACTERISTICS
CPU MT 6771 Octa-core 64-bit processor
4 core A73 + 4 core A53,2.0GHz
Memory RAM:2GB ROM:16GB(Standard)
RAM:4GB ROM:64GB(Optional)
Operating System Android 9.0
Extended memory Micro T card, up to 256GB
TELECOMMUNICATION
4G TD-LTEBand38/39/40/41

FDD-LTEBand1,2,3,4,7,17,20

3G WCDMA(850/1900/2100MHz);
2G GSM/GPRS/Edge(850/900/1800/1900MHz)
Data Rates 2.4G/5G dual-band, IEEE802.11a/b/g/n/ac
with WiFi roaming (seamless switching)
Bluetooth v4.2+ EDR w/ Bluetooth Low Energy
USER ENVIRONMENT
Operating Temp. -20℃~50℃
Storage Temp. -20℃~70℃
Humidity 5%~95% RH (non-condensing)
Sealing IP65
Drop Test Multiple 5 ft./1.5 m drops to concrete over the entire operating temperature range
DATA CAPTURE
1D Barcode
1D laser engine HoneywellN431X/other
Symbologies Code39、Code93、Code128、Codebar、

EAN-13、EAN-8、UPC-A、UPC-E、ITF14、

UCC/EAN-128、ITF25、Matrix25、EAN-128、ISBN etc.

2D Barcode
2D laser engine Zebra SE4710/Zebra SE2100/other
Symbologies PDF417,MicroPDF417,Composite,RSS,TLC-39,Datamatrix,QRcode,MicroQRcode,Aztec,

MaxiCode,PostalCodes,USPostNet,USPlanet,UKPostal,AustralianPostal,

JapanPostal,DutchPostal etc.

NFC(Option)
Working freq 13.56MHz
Protocol ISO14443A/B ISO15693, NFC-IP1,NFC-IP2 etc.
Tag supported M1 card(S50,S70),CPU card,NFC tags etc.
Read/Write range 5-10cm
BATTERY
Capacity Li-Ion 4900mAh & 9000mAh option  with fast charging
Standby time 360hrs if wireless communication are closed
Charging time <5hrs(support quick charge)
Working time 14+ hrs (full of charge)
ACCESSORIES
Standard 1xPower Supply; 1xLithium Polymer Battery;

1x Type-c charging cable

Option Charging dock
WARRANTY
Warranty One year
