Industrial Tablet Android Mobile RFID Reader UHF/HF/LF/Barcode (LP-917)

Category:

()The surprisingly rugged, thin and light tablet RFID reader

The thinnest and lightest of the full line of LightPioneer rugged tablet RFID readers, the LP-917 provide your workers with the same great styling they love on their personal tablet. You get a tablet built to handle all-day, everyday business, inside and outside your four walls. Large Screen 8 inch have bright, daylight viewable displays, and are loaded with featured barcode reader and optional HF/LF/UHF RFID reader that make data capture easy. And a wide range of accessories boost ruggedness, simplify charging, extend battery life and make this tablet easy to carry and easy to wear.

Features

Rugged and ready to use indoors and outside

Double the concrete drop specification from 1.2m with the optional rugged frame. The Corning® Gorilla® Glass display provides shatter- and scratch-resistance, protecting one of the most vulnerable components on any tablet. And vibration testing ensures this tablet is ideal for use in practically any vehicle, from forklifts in a warehouse to delivery and other trucks out on the road.

Class-best brightness and your choice of screen size with lightweight

The 8in. Mobile reader is ideal for information intensive apps, providing maximum display area and ultra lightweight 510g. You get class-best brightness that makes the LP-917 the easiest to read tablets in virtually any lighting conditions — including bright sunlight.

The power to run the most demanding apps

The fast ultra-low power processor combines with plenty of memory, allowing workers to run multiple apps simultaneously. And the processor minimizes power consumption, extending useful battery life.

Advanced data capture

Advanced enterprise-class scanning

Adopt Zebra/HoneyWell enterprise-class scan engine for 1D/2D scanning. No matter which scanning option you choose, you can count on superior scanning performance. Our scanners offer PRZM Intelligent Imaging and the

advanced algorithms, providing your workers with first-time every-time fast capture of virtually any 1D or 2D barcode in any condition — damaged, dirty or poorly printed.

High Efficient RFID Readers

The LP-917 RFID handheld terminal delivers next-generation modularity(HF/LF/UHF) with unique jacket design that enables customers to easily configure their device to suit a variety of applications and tasks.

This innovative UHF module utilize our advanced strong technology for a rapid, easy and selective contactless identification, offers an optimized ratio size/performance and low power consuming.



Specifications

LP-917 Industrial Tablet Android Mobile RFID UHF/HF/LF/Barcode  Reader
Operating System Android 8.1
CPU Qualcomm SD636,CPU 1.8GHz

Qcta core  Qualcomm® Kryo™ 260 CPU 64-bit

GPU Qualcomm® Adreno™ 509 GPU
RAM/ROM 3GB/32GB
4GB/64GB(option)
Extended Storage Micro SD, Maximum 128G
USB port 5 pin MicroUSB; Support to connect U-disk/Mouse/Keyboard/OTG line
HDMI HDMI port
OTG Through OTG can meet 100M network port, network card setup, PPPoE dial-up, web browsing. Support OTG extend RS232 serial port/485 serial port/RJ45 Serial port
External port Charge port, headphone port
Protection Grade
Industrial Protection Grade IP65
Drop Grade Drop resistance from 1.2m
Wireless Communication
Bluetooth Support 4.0
GPS GPS+BDS+A-GPS+GLONASS,  10m
High precise GPS: GPS+BDS,   3-5m
WIFI Support IEEE 802.11a/b/g/n/ac (2.4G and 5G bands)
4G LTE LTEB1/B3/B5/B7/B8/B20/B26/B34/B38/B39/B40/B41

WCDMA: B1/B2/B5/B8

GSM: B2/B3/B5/B8

TD-SDMA: 34/39

CDMA 1X/EVDO:BC0

Physical Parameters
Display Screen 8 inch LCD screen, 1920*1200 IPS 500 NITS brightness, capacitive touch screen
Keyboard Android menu, Homepage, Return, Volume, Barcode, ON/OFF, Reset
Camera 5 million pixels front camera, 13 million pixels rear camera with automatic focus and lighting function
Headset    3.5mm audio Interface, has MIC and Single loudspeaker
LED indicator light    Support (ordinary flicker, Call fast flicker, missed calls, charge indicator)
Flashlight Function Support, can be used for emergency lighting
         Google play store Support
  Gravity sensor Support
   Compass Support
Gyroscopes NOT Support
Acceleration sensors Support
Light and distance sensor Support
Vibrating motor Support
FM Support
Rechargeable Lithium Battery 3.8V, 6000mAh; Standby about 500 hours

Support Qi protocol wireless charging and USB QC3.0 fast charge.

Dimension 229.4*136.2*11.5mm
Weight 510g
Environmental Characteristics
Working Temperature -20℃ ~ +55℃
Storage Temperature -40℃ ~ +70℃
Humidity 5%-95% relative humidity; no condensation
Optional function
Barcode Scanning 1D Laser Scanner Index(In Jacket):

Honeywell N4313 or Zebra EM1350

Scanning speed: 104 times/second+12 times/second (two way scanning)

Scanning distance: 2.5cm-114.3cm

Scanning angle: 47±3°(default) /35±3°(reduced code)

2D Barcode Scanner Index(In Jacket):

Newlands EM3096 Or Honeywell N3680

Identification ability: 1D, 2D, OCR

Scanning angle: rotate 360°, incline±50°, deflection ±50°

Field of View: Horizontal 36°, vertical 23°

Depth of field: 4cm-23.5cm

Environmental luminance: 0~100,000 LUX

2D Barcode Scanner Index(In Host):

Zebra SE2100

RFID HF/NFC RFID(In Host):

Support NFC/NXP,13.56MHZ ISO14443A,B and ISO15693 protocol, reading distance 0-3cm,Tag support type:SR176,SRIX4K(TYPE-B),I-Code2,TI RFID Tag-it HF-I,EM4034,Mifare Classic ETC

LF RFID: 134.2KHZ LF RFID, support ISO11784/5 protocol, support to read IC card(FDX/HDX)
  125KHZ LF RFID, support to read ID card
UHF RFID



In Jacket

Supports EPC C1 GEN2/ ISO 18000-6C and ISO 18000-6B/6C protocol

Reading distance:3m/6m

Frenquency:865-868Mhz or 902-928Mhz

Ceramic antenna: 0.3db(25*25*4mm)

Far infrared meter reading Working frequency 37.9K
Fingerprint Just for locking the tablet mobile reader
