Alien H3 Chip RFID UHF Tag with 250 degree resistance (LP-4633-HT)

Alien H3 Chip RFID UHF Tag with 250 degree resistance (LP-4633-HT)

Categories: ,

Alien H3 Chip RFID UHF Tag with 250 degree resistance (LP-4633-HT)



Functional Specifications

Protocol  EPC C1G2 (ISO 18000-6C)
Operating frequency  902-928 MHz (US); 866-868 MHz (EU)
IC type Alien H3
Memory 512-bit user memory;
64-bit TID 96-bitEPC
Read rate 400 tags per second for 96-EPC bit number
Write Cycles 100,000 at 25℃
Data retention 50 years



Environmental Specification

Operating Temperature -40 to +250℃
Application Temperature -40 to +250℃
IP rate IP68
Attachment Adhesive
Warranty 1 year



Physical Specification and Read Range

Product model LP-4633-HT
Size LxWxH (mm) 46×33.8×6.5
Weight 17g
Avg read range on metal,4W EIRP 12m
Avg read range in metal,4W EIRP 6 m
Encasing Durable Paint



Radiation Pattern

Application

IT Assets

Healthcare Line

Industrial Management

Tool tracking

Other metal product
